Detach the “hot” lead (gray or blue) from the reverberation speaker terminal, strip it and connect it to the blue lead from the echo control with wire nut.ħ. Strip and connect it to the orange lead from the echo control with a wire nut.Ħ. Disconnect the reverberation input lead (green) from the main speakers. Connect the speaker end of the lead to the green lead from the echo control.ĥ. Connect the amplifier end of this lead to the red lead from the echo control with a wire nut. Remove 3/8″ of the insulation from each of the cut ends. Cut the green lead which connects the amplifier output to the main speakers. Position the console connector near the power amplifier so that the power and control cables will reach. From the back of the console, reach behind the tone generator and pull the cables throughģ. Push the cables through this opening into the console. Push a small screwdriver over the felt dust seal between the lower manual and the knee panel. Remove the organ back and pass the control cables into the console by the following method:Ĭlip the red and green interceptor plugs and sockets off the echo control cable and strip the wires 3/8″. Make sure the organ is turned off for the following steps.Ģ. Attach the echo and tremolo controls to the wooden rail in front of the lower manual with the black oxide screws provided. Weight: 147 pound net How to hook up a 251 to a Hammond Model A-100 using Leslie-kit 8253ġ.
